Sensar Acrylic IOL

Designed to produce long-term performance, the SENSAR IOL can help you give your patients the reliable, quality vision associated with our monofocal IOLs.

download pdf get a qoute

Technical Specifications

Model Numbers	AR40M	AR40E
OPTIC CHARACTERISTICS
Powers	-10.0 D to +15.0 D in 0.5 diopter increments	+2.0 D to +5.5 D in 0.5 diopter increments
Diameter	6.0 mm	6.0 mm
Shape	Meniscus	Biconvex
Material	UV-absorbing hydrophobic acrylic	UV-absorbing hydrophobic acrylic
Refractive Index	1.47 at 35°C	1.47 at 35°C
Edge Design	OptiEdge™ with 360° square posterior edge and round anterior edge	OptiEdge™ with 360° square posterior edge and round anterior edge
OPTICAL BIOMETRY
A-Constant (SRK/T)	118.7	118.7
AC Depth (HofferQ)	5.41 mm	5.41 mm
Surgeon Factor (Holladay 1)	1.63 mm	1.63 mm
APPLANATION ULTRASOUND BIOMETRY
A-Constant	118.4	118.4
AC Depth	5.2 mm	5.2 mm
Surgeon Factor	1.45 mm	1.45 mm
HAPTIC CHARACTERISTICS
Overall Length	13.5 mm	13.5 mm
Style	Modified C	Modified C
Material	Blue core polymethylmethacrylate (PMMA) monofilament	Blue core polymethylmethacrylate (PMMA) monofilament
