Tecnis 1-Piece IOL

The IOL you choose is the vision your patients take with them. Give them the excellent outcomes they deserve with the sharp vision, enhanced functionality, and long-term sustainability from the TECNIS 1-Piece IOL.

download pdf get a qoute

Technical Specifications

BIOMETRY	APPLANATION ULTRASOUND	OPTICAL
OPTIC CHARACTERISTICS
Model Number	ZCB00
Powers	+5.0 D to +34.0 D in 0.5 diopter increments
Diameter	6.0 mm
Shape	Biconvex, anterior aspheric surface, square optic edge
Material	UV-absorbing hydrophobic acrylic
Refractive Index	1.47 at 35°C
Edge Design	ProTEC frosted, continuous 360° posterior square edge
A-Constant	118.8	119.3
Theoretical AC Depth	5.4 mm	5.7 mm
Surgeon Factor	1.68 mm	1.96 mm
HAPTIC CHARACTERISTICS
Overall Diameter	13.0 mm
Style	C
Material	UV-absorbing hydrophobic acrylic
Design	Haptics offset from optic
